8
Compool Cp3810
Installation
High Voltage Wiring
Power Center with built in Sub-panel
At the equipment pad, mount the Power Center within
15’ of all the equipment. Provide power from the Main-
panel (located at the house) to Power Center.
Power Center without built in Sub-panel
At the equipment pad, mount a 100 amp
electrical circuit breaker panel (Sub-panel)
within 15’ of all the equipment. Provide
power from Main-panel (located at the
house) to the Sub-panel. Mount the Power
Center next to the Sub-panel.
