Comprehensive CHE-HDBT200 - 6 Application Example

6. Application Example
DVD or Blu-ray Player
IR Extender
CAT OUT SERVICE IR OUT DC 12V
HDMI IN
HDMI OUT
HDMI OUT DC 12VIR INSERVICECAT IN
LAN
Power Supply
LAN
UHDTV
UHDTV
Transmitter
Receiver
Cat 5e/6
7/7
IR blaster
