9.1.4 Dehumidification
Dehumidification can be checked by setting the humidity setpoint for an RH 10% below room
relative humidity. The compressor should come On. Return humidity setpoint to the desired
humidity.
9.1.5 Electric Panel
The electric panel should be inspected for any loose electrical connections
9.2 Steam Humidifier
The steam humidifier on System 2100 system is the most advanced OEM steam humidifier and
provides steady and reliable humidification using the same proven cylinder technology as Nortec’s
commercial NHTC. Depending on the unit configuration, the steam humidifier capacity can be range
from 5 to 30 lb/hr. Each steam humidifier has different size of mounting cabinet and replaceable
canister. Please refer to Error! Reference source not found. for the correct part number of the
humidifier. Refer to supplied installation and operation manual of the steam generator humidifier
for a complete guidance.
Figure 5 Steam Humidifier
