11 COMPONENTS IDENTIFICATION & ACCESS
11.1 FRONT LAYOUT (CONTROL BOX)
Figure 9 Sample Unit Shown*
*Actual unit may be different
NUMBER
NAME
1
DISCONNECT SWITCH
2
CONTACTORS
3
MOTOR PROTECTORS
4
MICROPROCESSOR CONTROLLER
5
TRANSFORMERS
3
1
2
4
5
