10 UNIT DIMENSIONS AND GENERAL COMPONENT LAYOUT
Figure 8. Unit Dimensions-Standard Unit shown
STANDARD CABINET
OF
Specialized Environmental Air Conditioning Systems
M. AHIR
9/20/2016
SYSTEM 2100 CAG/W EM 30 TON
K. WONGSO
682-905-035
11/28/2016
CONTROLLER GRAPHICAL
TOUCHSCREEN DISPLAY
LOCKING DISCONNECT
SWITCH
EC FAN MOTOR
ACCESS DOOR
COIL & BLOWER MOTOR
ACCESS DOOR
CONTROL PANEL
ACCESS DOOR
FRONT ACCESS
132.50
SUPPLY AIR
DUCT FLANGE
36" MIN. CLEARANCE
38" MIN. CLEARANCE 38" MIN. CLEARANCE
ALTERNATE
PIPING AND ELECTRICAL CONNECTION
LOCATION (KNOCKOUTS BY OTHER)
STANDARD PIPING AND ELECTRICAL
CONNECTION
HUMDIFIER & COMPRESSOR
ACCESS DOOR
UPFLOW W/ EC PLUG FANS
REAR RETURN
80.00
4.45
3.95 97.90
45.85
RETURN AIR DUCT CONNECTION
(1.5" DUCT COLLAR)
COIL
