1. Rear-facing installation (from birth to 13 kg)
0237-02
Important!
Do not use on seats
with airbags.
Extreme danger!
Turn the rotary handle at the front
of the seat shell upwards (1) and
at the same time push the seat
shell into the upright position (2).
Hold the seat shell with your
thumbs on the left and right side
and use your fingers to pull the
grey levers as far as they will go
in the direction of the arrow. Keep
the levers extended and lift the
seat shell upwards and out until
the green component is visible
above the snap mechanism.
Then release the levers and
remove the seat shell.
Insert the base unit into the car
seat as illustrated.
Position the reboard wedge
(green) as shown.
0014-07 0017-06 0013-04
A
I
R
B
A
G
1.2 1.31.1
