CONCORD Wanderer - Overview

2524
06 Wind shield
02 Handlebar
03 Adjustment
knob for
handlebar
17 Foot lever
for safety brake
13
Release lever with
safety adjustment knob
15
ProFix adapter
16 Adjustable straps
for tilt mechanism
12 Fastening
strap with
transportation lock
08 Adjustment
knob for footrest
05 Safety bar
18 Push-button
on rear wheel
_ OVERVIEW
01 Sunvisor
07 Adjustment knob
for safety bar
14 ProFix
controls
04 Seat unit
09 Footrest
10
Front wheel
lock
11 Cargo net
