Condec UPC5000 - 6 Available Ranges, Conversions and Resolutions

Available Ranges, Conversions and Resolutions 47
6.0 Available Ranges, Conversions and Resolutions
NOTE: All ranges are available in bars only.
Calibrator Mode:
@ = Gage Only
# = Absolute Only
$ = Gage or Absolute
NOTE: Calibrators have PSI and one conversion as shown in table.
A: kPa = PSI x 6.89476
B: mm Hg = PSI x 51.7149
C: Bar = PSI x 0.0689476
D: in Hg (0˚F) = PSI x 2.036
E: Kg/cm
2
= PSI x 0.070308
F: in H
2
O (60˚F) = PSI x 27.71
NOTE: Display resolution 0.02% of selected range, unless it is not devisable by 1, 2, or 5.
RANGE (PSI) A B C D E F
2000/1000/400
@,$ @,$ @,$
1000/500/200
@,$
$
@
$
@
500/250/100 $ $
@,$
100/50/25
@@
50/25/10
@
15/7.5/3
@
Table 6-1. PSI Conversion
CONVERSION
RANGES
HI/MED/LO
RESOLUTION
HI/MED/LO
PSI
2000.0/1000.0/400.0 0.5/0.2/0.1
kPa
13790/6895/2758.0 2/1/0.5
Kg/cm
2
140.62/70.31/28.125 0.02/0.1/0.005
in H
2
O
55420/27710/11084 10/5/2
Table 6-2. Resolutions (2000/1000/400 PSI ranges)
