8.0 Specifications
Pressure Specifications:
Pressure range: Three independent pressure ranges per
instrument. See “Part Number System” on
page 36 for available ranges
Available Pressure
Calibrations: Gage only, absolute only, or
gage and absolute
Overall Accuracy: < ±0.05% Full Scale Max. Accuracy
statement includes all effects of linearity,
hysteresis, repeatability and ambient
temperature
Operating Temperature: +40° to +122°F (+4.4° to +50.0° C)
Storage Temperature: 0° to +185° F (–17.8° to +85°C)
Pressure Media: Dry gaseous nitrogen, standard
Internal Pressure Cylinder:
Capacity: 7.0 ft
3
N
2
@ 2216 PSIG
Volume: 80 in
3
Rating: 2216 PSIG
Test Pressure: 3360 PSIG
Material: 6061 Aluminum
Pressure Supply Gage:
Size: 2-in. diameter
Range: 0–3000 PSIG
Test Pressure: 4500 PSIG
Over-pressure Rupture Disk:
Rating: 3000 PSIG, nominal
Type: Stainless steel outer case
Pressure Media Filter:
Rating: 20 microns, Test Port
Type: Field replaceable
Orion-2C Control Valve:
Type: Micro-metering with replaceable soft seat
Material: Aluminum body, clear anodized aluminum
knobs, black anodized. All other parts 300
series stainless steel
Relief Valve:
Type: Adjustable, atmospheric bleed
Setting: Adjustable to 10% above highest
calibrated pressure
Material: 300 series stainless steel
Internal Piping:
Tubing: 1/8 in. O.D., 0.030 in. wall thickness
seamless Cu
Couplings: Brass, Swagelok type
Fill Port:
Style: Quick-disconnect.
Pressure Rating: 3000 PSIG connected, 2000 PSIG
disconnected
Material: 300 series stainless steel
Test Port:
Pressure Rating: 5000 PSIG
Material: 300 series stainless steel
Vent Port:
Style: 1/4" 37° AN male
Pressure Rating: 2500 PSIG
Material: Brass
Pressure Hoses:
Quantity Supplied: Two; one input, one output
Length: 5 ft. nominal, each hose
Style: Fill (input) hose
- Nylon-lined core tube with
synthetic braid, polyurethane cover. Fitted
with quick-disconnect (Brass) socket on
one end and 1/4" 37˚ female AN swivel
pressure fitting on opposite end
T
est Port (output) hose - Nylon-lined core
tube with synthetic braid, polyurethane
cover. Fitted with quick-disconnect plug
(St Stl) on one end and 1/4" 37˚ female AN
swivel tube coupling on the other
Pressure Limit Control Regulator:
Type: Single stage, self-venting, non-bleed
Pressure Rating: 3000 PSIG max. inlet
Internal Pressure Sensor:
Type: Bonded, metal foil strain gage, sputtered
thin-film or equivalent
Sensitivity: 3 mV/V nominal
Construction: Completely weld-sealed stainless steel
outer body and pressure cavity
Battery:
Type: Rechargeable, lead-acid gel
Nominal Voltage: 12V
Approx. Weight: 2.86 lbs
Case: Polystyrene/H.I. ABS
Carrying Case UPC5000 only:
Type: Aluminum case with latched cover and
handle
Material Thickness: 0.090 in., nominal
Finish: Enamel paint, textured finish
Color: Gray
Control Panel:
Material: Aluminum (5052-H32)
Thickness: 0.125 in
Finish: Gray enamel paint with black silkscreen
nomenclature
Physical Specifications:
Weight: 34 lbs. including all hoses and cables
UPC5000 Case Dim’s: 10" wide x 16" long x 11.5" high
UPC5010 Case Dim’s: 19" wide x 8.1" deep x 10.5" high
(Case dimensions excluding front handles)
