Conel FLOW - 4 Technical Data

18
4. Technical data
Technical data
Article number FLOWTPF
Pressure outlet > G 1¼“ female thread
> G 1¼“ female thread adaptor
> G ¾“ male thread adaptor; hose
connection 1“ and ¾“
Max. flow (at 1 m) 6.4 m
3
/h
Max. head (at 0 m
3
/h) 6.2 m
Switch on
Switch off
20 mm
1 mm
Free passage 1 mm
Power cable H07RN-F 3G1.0
Cable length 10 m
Weight Approx. 3.2 kg
Voltage/frequency 1 x 230 V/50 Hz
Current type Alternating current
Nominal current 1.6 A
Motor power P1 0.36 kW
Speed 2900 rpm
Motor protection Temperature monitor built into winding
Plug Europlug
Protection class IP 68
Motor insulation class B
Motor protection activation tempe-
rature
120 °C
Maximum immersion depth 10 m
Fluid temperature Max. 40 °C, 60 °C for 5 min
Technical data
