Conel FLOW - 9 Appendix

21
Appendix
9. Appendix
290 mm
175 mm
51.5 mm
157 mm
1 mm
20 mm
A
B
290 mm
175 mm
51.5 mm
157 mm
1
1 mm
20 mm
A
B
2
3
4
TPF
1 2 3 4 5 6 7 8
0.5 1 1.5 2
1
2
3
4
5
6
7
Pump Curve 50 Hz
H = total head
Q = discharge volume
Curve to ISO 9906
Figure 1
Figure 2 Figure 2.1
Illustration with G 1¼“ adaptor
1. ¾“ hose connection
2. G ¾“ external thread
3. 1“ hose connection
4. G 1¼“ external thread
5. Non-return valve
