3 Pro d u c t d e s c r ip t io n
ENGLISH
3 Pr o d u c t d e s c r ip t io n
3.1 General information on photovoltaic systems
A grid-connected photovoltaic system essentially consists of
the following components:
| Solar power system (1)
The solar power system consists of several photovoltaic
modules connected in sequence or in parallel.
| Safety system
|DC wiring (2)
|DC disconnect (3)
|Inverter (4)
|AC wiring
| AC disconnect (5)
| Meter cabinet with circuit allocation, consumption and
feed-in meter and house connection (6)
Fig. 3-1: House with photovoltaic system
(1)
(2)
(3)
(4)
(5)
(6)
