Procedure
1. Before setting up the appliance, check it for any externally visible damage.
Under no circumstances should you use a damaged appliance. A damaged
appliance could be dangerous
2. Remove Terminal Tamper cover (Figure2)
3. Mark wall and drill mounting holes (Figure 4)
4. Mount meter on the wall and secure
5. Ensure upstream breaker is in the off position
6. Connect the incoming live supply to L LINE (Figure 3).
7. Connect the incoming neutral supply to N LINE (Figure 3)
8. Connect the outgoing live supply to L LOAD (Figure 3)
9. Connect the outgoing neutral supply to N LOAD (Figure 3)
10. Ensure that all terminal screws are securely tightened, all cables are securely
held in place and that no bare wiring is exposed
11. Secure the terminals & enclosure by threading steel wire through the security
holes and crimping (If required)
12. The meter must be installed on a solid flat surface with a 4mm screw
13. For indoor use only, can be installed in an enclosure or stand alone
