Conrad FSP550-80GLC - C) 3.5 Plug; D) 4-Pin ATX12 V Plug (400 W Version); E) 2*4-Pin ATX12 V Plug (550 W Version); F) SATA Mains Plug

36
c) 3.5" plug
+12V= (yellow)
ground (black)
ground (black)
+5V= (red)
d) 4-pin ATX2.0-12V plug (400W version)
+12V= (yellow) ground (black)
+12V= (yellow) ground (black)
e) 2*4-pin ATX2.0-12V plug (550W version)
+12V (blue/yellow) ground (black)
+12V (blue/yellow) ground (black)
+12V (green/yellow) ground (black)
+12V (green/yellow) ground (black)
If you are using a mainboard with 4-pin ATX2.0-12V plug, you have to separate the two
plugs and use the 4-pin plug with the green/yellow cables.
The plug with the two blue/yellow cables must not be used!
f) SATA mains plug
+12V= (yellow)
ground (black)
+5V= (red)
ground (black)
3.3= (orange)

Since the strips in the SATA plug are not
suitable for high currents, the five connecting
cables are distributed to several contacts.
