Constellation PEGASUS - Top View; Side View

GB
10
1 2 3
4
5 6
MIC
Top View
1. NFC Sensor
2. Bluetooth® Button
3. – Volume Button
4. + Volume Button
5. ON/OFF Button
6. MIC
Side View
1. AUX IN Socket
2. RESET Button
3. Charging Port
1
2
3
Open the plastic cover at the side of
the unit for the connector panel shown
above.
