6.4 Riemenspannung
Lösen Sie die vier Befestigungsschrauben
des Motors. Dafür müssen Sie im vorderen
Bereich das Blech über dem Riementrieb
entfernen und im hinteren Bereich das Blech
hinter der Spindel. Mit Hilfe einer M10er
Mutter am hinteren Ende des
Riemenspannbleches (Anhang Skizze Pos
101) unter dem Motor können Sie die
Spannung des Riemens verändern. Der
Zahnriemen der DELTA II sollte auf halben
Weg zwischen Umlenkrolle und Motorwelle
einen halben Zentimeter hin und her gerückt
6.4 Belt tension
Loosen the four fixing screws of the motor.
To do this you must remove the front belt
cover and the cover behind the Spindle. By
turning an M10 Nut on the rear side of the
belt tensioner (metal plate underneath the
motor Appendix diagram No. 101) the
tension of the belt can be adjusted. The tooth
belt of the DELTA II should be able to move
halve a centimetre forwards and backwards
half way between the pulley and the motor
shaft.
7 Wechsel der Magnetscheiben
und Werkzeuge
7 Changing of the magnetic discs
and tools
Achtung: Vor Wartungsarbeiten Motor
zum Stillstand bringen und Netzstecker
ziehen.
Achtung: Werkzeuge können nach
gebrauch sehr heiß sein.
- Maschine über die Hinterräder kippen
und umlegen.
Wechseln der Werkzeuge:
- Die einzelnen Werkzeuge werden durch
Magnete in einem konischen
Schwalbenschwanz gehalten. Durch
leichtes Hämmern (Gummihammer im
Lieferumfang) auf die Werkzeuge in
Richtung Scheibenmitte werden diese
gelöst und können abgenommen werden.
Neue Werkzeuge dann von innen nach
außen in den Schwalbenschwanz
schieben und festdrücken.
Wechseln der Magnetscheiben:
- Die Magnetscheiben für Werkzeuge
(Anhang Werkzeuge Pos 11) werden mit
jeweils drei Sechskantschrauben auf der
Werkzeugaufnahme (Anhang Explo-
sionszeichnung Pos 67) gehalten.
- Durch Lösen der Schrauben können die
Attention: Before working on the
grinder bring the motor to a total stand
still and disconnect from the power
supply.
Attention: Tools can be hot after use.
- Tilt the machine onto the back wheels
and rest it on the bar underneath the
control panel.
Changing of the tools:
- The tools are hold by a magnet in a
conical dovetail guide. By softly
hammering on the tool in direction of the
centre of the disc the tool gets loose and
can be removed. To fix new tools slide
them from the inside of the disc to the
outside into the dovetail guide.
Changing the magnetic disc:
- All discs for segment plates (Appendix
diagram No. 11) are secured to the tool
brackets (Appendix diagram No. 67) by 3
hex bolts.
- By loosening the bolts, the discs can be
removed.
- Check the grinding tool for wear or
damage ready for the next application.
Fix new tools according to the appendix
