Starts the Acquisition of the device. The
number of frames captured is specified
by AcquisitionMode.
Stops the Acquisition of the device at
the end of the current Frame. It is
mainly used when AcquisitionMode is
Continuous but can be used in any
acquisition mode.
AcquisitionFrameCount
Min: 1
Max: 255
MultiFrames acquisition mode. Sets the
number of frames to acquire when a
valid trigger is received.
Controls the acquisition rate (in Hertz)
at which the frames are captured.
AcquisitionLineRateEnable
AcquisitionLineRateEnable
False/True
Enables setting the camera's acquisition
frame rate to a specified value
AcquisitionStatusSelector
AcquisitionStatusSelector
AcquisitionTriggerWait
FrameTriggerWait
Selects the internal acquisition signal to
read using AcquisitionStatus.
Device is currently waiting for a trigger
to capture one or more frames.
Device is currently waiting for a frame
trigger.
AcquisitionStatus
True /False
Reads the state of the internal
acquisition signal selected using
AcquisitionStatusSelector.
TriggerSelector
Acquisition Start/Frame
Start/ Line Start
Selects which type of trigger to
configure .
Controls the enable state of the
selected trigger.
(The selected trigger is turned off.)
(The selected trigger is turned active.)
Generates an internal trigger. This
feature is available when TriggerMode
is set to ON and TriggerSource is set
to Software.
Specifies the internal signal or physical
input line to use as the trigger source.
The selected trigger must have its
TriggerMode set to ON.
Trigger Activation
RisingEdge
Select the activation mode for the
selected Input Line trigger source.
The trigger is considered valid on
the rising edge of the line source signal
