Control Techniques 01100017 User Manual

14 Unidrive M300/HS30 Quick Start Guide
Issue Number: 7
Table 4-2 Braking resistor resistance and power rating (200 V)
Table 4-3 Braking resistor resistance and power rating (400 V)
* Resistor tolerance: ±10 %
Model
Minimum
resistance*
Ω
Instantaneous
power rating
kW
Continuous
power rating
kW
01200017
130 1.1
0.25
01200024 0.37
01200033 0.55
01200042 0.75
02200024
68 2.2
0.37
02200033 0.55
02200042 0.75
02200056 1.1
02200075 1.5
03200100 45 3.3 2.2
04200133
22 6.0
3.0
04200176 4.0
Model
Minimum
resistance*
Ω
Instantaneous
power rating
kW
Continuous
power rating
kW
02400013
270 2.2
0.37
02400018 0.55
02400023 0.75
02400032 1.1
02400041 1.5
03400056
100 6.0
2.2
03400073 3
03400094 4
04400135
50 11.2
5.5
04400170 7.5

Control Techniques 01100017 Specifications

General

Brand	Control Techniques
Model	01100017
Category	Controller
Language	English
