Unidrive M300/HS30 Quick Start Guide 19
Issue Number: 7
Figure 4-5 Pr 05 = PrESEt
* Refer to the Control User Guide.
Figure 4-6 Pr 05 = PAd
1
2
4
0V
Voltage speed reference
input (AI 1)
Reference select
5
7
Analog output 1
(motor frequency)
+ 10 V output
Digital output
(zero frequency)
9
10
11
Unassigned
12
13
14
Reference select
Run forward
+ 24 V output
Run reverse
Terminal5 Terminal14
Reference selected
0
0
1
1
0
1
0
1
Preset speed 1*
Preset speed 2*
Preset speed 3*
Preset speed 4*
1
2
0V
Voltage speed reference
input (AI 1)
7
Analog output 1
(motor frequency)
9
10
11
Digital output
(zero frequency)
Unassigned
12
13
14
Analog input 1/
input 2 select
Run forward
+ 24 V output
Run reverse
4
5
+ 10 V output
Voltage speed reference
input (AI 2)
When Pr 05 is set to PAd, to run in
reverse:
•Set Pr 17 to On
The Keypad reference can now be
set to a negative frequency to run the
motor in the reverse direction.
