Unidrive M300/HS30 Quick Start Guide 27
Issue Number: 7
27
Power-up Keypad
Control Mode
Reference
rESEt (0), LASt (1), PrESEt (2) rESEt (0) RW Txt US
28 Ramp Mode Select
Fast (0), Std (1), Std.bst (2),
Fst.bst (3)
Std (1) RW Txt US
29 Ramp Enable Off (0) or On (1) On (1) RW Bit US
30 Parameter Cloning
NonE (0), rEAd (1), Prog (2),
Auto (3), boot (4)
NonE (0) RW Txt NC US
31 Stop Mode
CoASt (0), rP (1),
rP.dc I (2),
dc I (3), td.dc I (4),
diS (5),
CoASt (0), rP (1),
rP.dc I (2),
dc I (3),
td.dc I (4), diS (5),
No.rP (6)
rP (1) RW Txt US
32
Dynamic V to F
Select / Flux
Optimization Select
0 to 1 0 RW Num US
33
Catch A Spinning
Motor
dis (0), Enable (1), Fr.Only (2),
Rv.Only (3)
dis (0) RW Txt US
34 Digital Input 5 Select
Input (0), th.Sct (1), th (2),
th.Notr (3), Fr (4)
Input (0) RW Txt US
35
Digital Output 1
Control
0 to 21 0 RW Num US
36
Analog Output 1
Control
0 to 14 0 RW Txt US
37
Maximum Switching
Frequency
0.667 (0), 1 (1), 2
(2), 3 (3), 4 (4), 6
(5), 8 (6), 12 (7),
16 (8) kHz
2 (2), 3 (3),
4 (4), 6 (5),
8 (6), 12 (7),
16 (8) kHz
3 (3) kHz RW Txt US
38 Autotune 0 to 2 0 to 3 0 RW Num NC US
39
Motor Rated
Frequency***
0.00 to 550.00 Hz
Def.50: 50.00 Hz
Def.60: 60.00 Hz
RW Num RA US
40
Number of Motor
Poles****
Auto (0) to 32 (16) Auto (0) RW Num US
41 Control Mode
Ur.S (0), Ur (1), Fd
(2), Ur.Auto (3), Ur.I
(4), SrE (5),
Fd.tap (6)
Ur.I (4) RW Txt US
42
Low Frequency
Voltage Boost
0.0 to 25.0 % 3.0 % RW Num US
43 Serial Baud Rate
600 (1), 1200 (2),
2400 (3), 4800 (4), 9600 (5),
19200 (6), 38400 (7), 57600 (8),
76800 (9), 115200 (10)
19200 (6) RW Txt US
44 Serial Address 1 to 247 1 RW Num US
45
Reset Serial
Communications
Off (0) or On (1) Off (0) RW Bit ND NC US
46
Brake Controller
Upper Current
Threshold
0 to 200 % 50 % RW Num US
47
Brake Controller
Lower Current
Threshold
0 to 200 % 10 % RW Num US
48
Brake Controller
Brake Release
Frequency
0.00 to 20.00 Hz 1.00 Hz RW Num US
49
Brake Controller
Brake Apply
Frequency
0.00 to 20.00 Hz 2.00 Hz RW Num US
50
Brake Controller
Brake Delay
0.0 to 25.0 s 1.0 s RW Num US
Parameter
Range
(Ú) Default (Ö)
Type
OL RFC-A OL RFC-A
