34 Unidrive M300/HS30 Quick Start Guide
Issue Number: 7
Set to the rated speed of the motor (taken from the motor name plate). The motor rated speed is
used to calculate the correct slip speed for the motor.
* With Unidrive HS30, the maximum is 80,000.0 rpm.
The Rated Voltage (Pr 08) and the Rated Frequency (Pr 39) are used to define the voltage to
frequency characteristic applied to the motor. The Rated Frequency (Pr 39) is also used in
conjunction with the Motor Rated Speed (Pr 07) to calculate the rated slip for slip compensation.
Enter the motor rated power factor cos
ϕ (taken from the motor name plate).
The drive can measure the motor rated power factor by performing a rotating autotune (see Autotune
(Pr 38).
07 Motor Rated Speed
RW Num US
OL
Ú
0.0 to 33000.0 rpm*
Ö
Def.50: 1500.0 rpm
Def.60: 1800.0 rpm
RFC-A
Def.50: 1450.0 rpm
Def.60: 1750.0rpm
08 Motor Rated Voltage
RW Num RA US
OL
Ú
0 to 240 V or 0 to 480 V
Ö
110 V drive: 230 V
200 V drive: 230 V
400 V drive 50 Hz: 400 V
400 V drive 60 Hz: 460 V
RFC-A
09 Motor Rated Power Factor
RW Num RA US
OL
Ú
0.00 to 1.00
Ö
0.85
RFC-A
10 User Security Status
RW Num ND PT US
OL
Ú
LEVEL.1 (0), LEVEL.2 (1),
ALL (2), StAtUS (3), no.Acc (4)
Ö
LEVEL.1 (0)
RFC-A
To Next Page
