Used to set-up a user security code. See section 5.6 Security codes on page 18.
0: keypad reference is zero
LASt:keypad reference is last value selected before the drive was powered down
PrS1:keypad reference is copied from preset speed 1
nO: do nothing
rEAd:program the drive with the contents of the SmartStick
Prog:program the SmartStick with the current drive settings
boot: SmartStick becomes read only. The contents of the SmartStick will be copied to
the drive every time the drive is powered up.
Parameter cloning is initiated by pressing the MODE key on exit from parameter edit
mode after Pr 28 has been set to rEAd, Prog or boot.
nO: defaults are not loaded
Eur: 50Hz default parameters are loaded
USA: 60Hz default parameters are loaded
Default parameters are set by pressing the MODE key on exit from parameter edit
mode after Pr 29 has been set to Eur or USA.
When default parameters have been set, the display will return to Pr 01 and Pr 10 will be
reset to L1.
0: Fast ramp selected
1: Standard ramp with normal motor voltage selected
2: Standard ramp with high motor voltage selected
3: Fast ramp with high motor voltage selected
Fast ramp is linear deceleration at programmed rate, normally used when a braking
resistor is fitted.
Standard ramp is controlled deceleration to prevent DC bus over-voltage trips, normally
used when there is no braking resistor fitted.
No Function Range Defaults Type
25 Security set-up 0 to 999 0 RW
No Function Range Defaults Type
26 Not used
No Function Range Defaults Type
27 Power up keypad reference 0, LASt, PrS1 0 RW
No Function Range Defaults Type
28 Parameter cloning nO, rEAd, Prog, boot no RW
M
If parameter cloning is enabled when no SmartStick is fitted to the drive, the drive’s
display will flash FAIL twice before changing back to nO.
NOTE
No Function Range Defaults Type
29 Load defaults nO, Eur, USA no RW
M
The drive must be in a disabled, stopped or tripped condition to allow default parameters
to be set. If default parameters are set while the drive is running, the display will flash
FAIL twice before changing back to nO.
NOTE
No Function Range Defaults Type
30 Ramp mode select 0 to 3 1 RW
