Control Techniques UD70 Installation Guide

1 UD70/MD29 Installation Guide
www.controltechniques.com Issue Number: 3
1 Mechanical Installation
Before attempting to install option modules or cards, ensure that the Unidrive
or Mentor II is switched off. AC Drives should be left for 5 minutes to ensure
that the DC link capacitors have completely discharged.
1.1 Unidrive and UD70
• Slide the UD70 module under the display panel of the Unidrive, and push the
module in until the connector locates with the plug inside the Unidrive.
NOT E
