Control Techniques Unidrive M700 User Manual

www.controltechniques.com 11
Permanent Magnet Motor Setup
Closed loop
Unidrive M70x closed loop permanent magnet motor setup
Parameter description Parameter Comments
USA defaults 00.000 = 1254 Drive USA defaults (60 Hz)
00.048 (11.031) = 3 (RFC-S) Rotor Flux Control-Synchronous
Reset the drive RESET Red button on keypad
User security status 00.049 (11.044) = 1 (All menus)
Reference selector 00.005 (01.014) = 4 (Keypad) Keypad control
Reset the drive RESET Red button on keypad
Max reference clamp 00.002 (01.006) = Set to 1.2 x Pr 05.008 (rpm)
Acceleration rate 00.003 (02.011) = 2.000 s/1000 rpm
Deceleration rate 00.004 (02.021) = 2.000 s/1000 rpm
Ramp mode 00.015 (02.004) = Standard "Fast" ramp if braking resistor
installed. Also ensure Pr 10.030, Pr
10.031 & Pr 10.061 are set correctly.
Catch a spinning motor 00.033 (06.009) = 0 (Off)
Max switching frequency 00.041 (05.018) = Motor nameplate value (min.Fsw)
(kHz)
Number of motor poles 00.042 (05.011) = Motor nameplate value
Motor rated voltage 00.044 (05.009) = Motor nameplate value
Rated speed 00.045 (05.008) = Motor nameplate value
Motor rated current 00.046 (05.007) = Motor nameplate value
Volts per 1000 rpm 00.047 (05.033) = Motor nameplate value
Drive encoder lines per rev 03.034 = 1024 (Lines) Encoder technical info
Drive encoder supply voltage 03.036 = 0 (5V) Encoder technical info
Drive encoder type 03.038 = 0 (AB servo) 0 (AB servo) encoder technical info
Current reference filter 04.012 = 0.2 ms Current reference filter 1 time constant
High speed mode 05.022 = -1 (Limit)
Stop mode 06.001 = 1 (Ramp) No ramp is default
Hold zero speed 06.008 = 0 (Off)
Reset the drive RESET Red button on keypad
Save parameters to NVM 00.000 = 1001
Reset the drive RESET Red button on keypad
Perform an autotune
Warning: A rotating autotune will cause the motor to accelerate up to 2/3 base speed in the
direction selected regardless of the reference provided. Once complete the motor will coast to a
stop. The enable signal must be removed before the drive can be made to run at the required
reference.
Autotune 00.040 (05.012) = 2 Motor loaded stationary autotune = 1
Motor unload/uncoupled autotune = 2
Close drive Safe Torque Off signal(s) – M700/701: (jumper terminal 22 to terminal 31);
M702: (jumper Terminals 2, 11, and 13)
Press keypad RUN (green) button
***** Wait for drive/motor to stop rotating and display “Ready” or “Inhibit” *****
Save parameters to NVM 00.000 = 1001
Reset the drive RESET Red button on keypad
Open Drive Safe Torque Off signal(s) – M700/701: (remove jumper from T22 to T31);
M702: (remove jumpers from T2, T11, and T13)
Save parameters to NVM 00.000 = 1001
Reference selector 00.005 (01.014) = 0 (AI A2) Terminal strip control
Reset the drive RESET Red button on keypad
