Controls 58-E4800 User Manual

Manuale di Istruzioni
Instruction Manual
58-E4800 Rev. 4 EN 21/05/2012
15
2.3 Technical specifications
Main characteristics
Product Strumento ad ultrasuoni
Manufacturer
CONTROLS Cernusco s/N (MI) Italy
Product code
58-E4800
Single-phase line voltage
100 VAC/240 VAC +6%, -10%
Frequency 50/60 Hz
Max. current 90mA
Method of power entry
“Multirange” external battery charger with
dedicated output cable
Batteries Rechargeable, R6 AA size, 1,2V – 2400 mAh
Transit time measurement From 0.1 to 1999.9 microseconds
Pulse rate Selectable 1, 2, 5, 10 pulse per second
Resoluction 0.1microseconds
Transmitter output 1200V
Frequency range From 24toa 150KHz (standard probe 54KHz)
Receiver input impedance 1MOhm
Net weight (approax.) 0,5 Kg
Dimensions [mm] 240x120x75 mm
Environmental conditions
Operating temperature
+ 10  + 40°C
Operating humidity
≤ 50%RH @ 40°C

Controls 58-E4800 Specifications

General

Brand	Controls
Model	58-E4800
Category	Test Equipment
Language	English
