Controls EMGRT1 User Manual

CONTROLS, INCORPORATED
CONTROL SYSTEMS & SOLUTIONS
- 11 -
10.2 TTL Outputs
10.2.1 When active the outputs sink to 0 VDC.
10.2.2 When not active, the outputs stay at +5 VDC
39 Low Oil Pressure Shutdown
40 High Temp Shutdown
41 Low Fuel Level Shutdown
42 Over Speed Shutdown
43 Over Crank Shutdown
44 Engine Run Indicator

Controls EMGRT1 Specifications

General

Brand	Controls
Model	EMGRT1
Category	Controller
Language	English
