CONTROLS, INCORPORATED
CONTROL SYSTEMS & SOLUTIONS
- 12 -
11) Dipswitches
11.1 Dipswitch Definitions
Dipswitch 1 Not Used
Dipswitch 2 Not Used
Dipswitch 3 Not Used
Dipswitch 4 Not Used
Dipswitch 5 Turn ON to enable the Self Charging Battery System (SCBS)
Dipswitch 6 Not Used
Dipswitch 7 Not Used
Dipswitch 8 Not Used
NOTE: Glow plug and auto start time delays are enabled via the “Sender Configuration” menu.
11.2 Changing Dipswitch Settings - When making a dipswitch setting change, it is necessary to cycle the power
to the controller before the new setting becomes active. (except dip switch 2)
12) Self Charging Battery System
The Self Charging Battery System (SCBS) included with this control is designed to maintain a high level of battery
capacity during extended periods of standby operation. However, care must be taken when using this system due
to the ability of the control to start and run the engine while in the “Auto” mode.
Conditions
1) Control must be in “Auto”.
2) Dipswitch 5 must be in the ON position.
3) Displayed DC Voltage must be at or below 12.2 VDC for 1 minute.
Results
1) Control will begin the 8-second countdown to starting.
2) Control will start and run the engine at the programmed Warm Up speed for 15 minutes. During this run the
display will flash a message of “Engine Start Low Battery Charge”.
3) Control will stop the engine and wait a minimum of 60 minutes before the SCBS will initiate another run.
