Primary Connector (14 Pin)
Pin
Function
Pin
Function
1
Relay #2 -ECU Signal
8
J1939 Low
2
Relay #1 NO
9
Relay #3 Common
3
Relay #3 NO
10
Not Used
4
Relay #2 & #4 Common
11
Battery Positive
5
Relay #4 NO
12
Battery Negative
6
Relay #1 Common
13
Fuel Level
7
J1939 High
14
DI #1 Hydro-Throttle
Secondary Connector (23 Pin)
Pin
Function
Pin
Function
Pin
Function
1
Relay #5
9
Relay 5/6 Common
16
Relay #6
2
DI #10
10
DI #14
17
DI #2 Override
3
DI #11
11
DI #15
18
DI #3 E-Stop
4
DI #12
12
DI #16
19
DI #4 Low Water
5
DI #13
13
MODBUS A
20
DI #5
6
DI #8
14
MODBUS B
21
DI #6
7
DI #9
15
Relay #7
22
DI #7
8
Relay 7/8 Common
23
Relay #8
Note: Modbus is available as an option in the C Series 200 Level product. Consult with a
factory sales engineer for ordering.
CAUTION:
Maximum current draw for signal circuits is 5 amps
