Main Menus
Main Menus
Sub Menus
Active Engine Fault Codes
View/Scroll Active Fault Codes
Stored Engine Fault Codes
View/Scroll Stored Fault Codes
Engine Parameters
View ECU Engine Information
(% Load, Torque, Oil Temp, etc.)
Engine Identification
Engine Model # View
Engine Serial # View
Module Information
Control Unit Part# View
Control Unit Software Version View
Controller Setup
Input Configuration
(1)
(PASSWORD PROTECTED)
Throttle Configuration
(2)
Module Configuration
(3)
CAN Configuration
(4)
Emission Configuration
(5)
MOD bus Configuration
(6)
To access the controller setup menus, a password is required. The password
is 4345.
Viewing Menus
Configuration
Menus
