Configuration Menus
(1)
Input Configuration
Analog 1 Function
Digital In Normally [Open/Closed]
Digital In Action [Discrete Speed Override]
Digital In Message [None]
Digital In Check [Always]
Digital B1 Action [Throttle Up]
Digital B2 Action [Throttle Down]
(2)
Throttle Configuration
Throttle Type - Throttle Type Selection
TSC Min Speed Selection
TSC Max Speed Selection
TSC Bump Speed
TSC Ramp Rate Selection
Throttle Curve Selection
Multistate Speed 1-4
Discrete Speed 1
Discrete Speed 2
(3)
Module Configuration
Display Units (English, Metric)
Hour meter Source (Engine ECU, Internal)
Battery Source (J1939, Internal)
Battery Volt Trim
Pre Alarms Displayed
(4)
CAN Configuration
Source Address (Default = 44) Others available
TSC1 Address (Default = 3) Others available
Engine Address (Default = 0) Others available
Engine Type (John Deere)
Oil/Fuel Transmit
(5)
Emissions Configuration
DEF Level Check
Low DEF Pre Alarm
TSC Regen Speed
Allow Service Regen
Regen Interlock
TSC Transmit
DPF Inhibit Lamp Source
