Controls MVP-62350 User Manual

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
12
Configuration Menus
(1)
Quick Setup
Engine Type – Default = Mechanical
Flywheel Teeth
Preheat Time
Performance Display Off/On
(2)
Eng. Parameter Configuration
Engine Type
Parameter Selection (Speed, Coolant Temp., Oil Pressure, Fuel Level,
Voltage, Hour Meter)
Parameter Setup (Varies based on parameter)
(3)
Input Configuration
Configure Selection (Channels/Message)
Digital 1 Setup
(4)
Output Configuration
Configure Selection (Channels/Message)
Relay 1 Function (Default to Fuel/Run)
Relay 2 Function (Default to Preheat)
Relay 3 Function
(5)
Throttle Configuration
Throttle Type
Cooperative TSC Mode
TSC Minimum Speed
TSC Maximum Speed
TSC Bump Speed
TSC Ramp Rate
Throttle Curve
Multi State Speeds 1-4
(6)
Engine Safety Configuration
Sender Check By-Pass (Default = 0:10)
Parameter Selection (Fuel Level, Oil Pressure, Temperature, Battery,
Overspeed, Speed Limit, Derate to Shutdown)
Parameter Settings (vary based on selection)

Controls MVP-62350 Specifications

General

Brand	Controls
Model	MVP-62350
Category	Control Panel
Language	English
