Indicator Lamps
Active and Stored Engine ECU Codes
The panel also provides the ability to check the engine ECU for all ACTIVE and STORED engine ECU
codes. These codes can be viewed via the Active Codes and Stored Codes menus.
Engine
Alarm/Fault
Lamp
Amber
Warning
Lamp
Regen
Active
Lamp
DPF
Lamp
Regen
Inhibit
Lamp
Low
DEF
Lamp
Malfunction
Lamp
Engine
MILL
Lamp
