CONTROL PANEL SPECIFIC ALARMS AND SHUT DOWNS
The panel has its own engine safety alarms and shut downs that can be enabled. These alarms and
shut downs are managed by the control panel. The available options are listed below and can be
accessed via the Engine Safety Configuration menu.
Each alarm must be enabled in the Engine Safety Configuration menu to activate.
Heading
Default
Range
Units
Sender Check Bypass
0:10
0:05 – 1:00
Min:Sec
Fuel Level Check
Off
Off / Always / Run
Low Fuel Pre Alarm
20
0 - 100
%
Low Fuel Alarm
1
0 - 100
%
Fuel Alarm Delay
0:05
0:01 – 1:40
Sec
Fuel Level Alarm Action
Shutdown
Oil Pressure Check
Run
Off / Always / Run
Low Oil Press Pre Alarm
15
0 - 100
PSI
Low Oil Press Alarm
10
0 - 100
PSI
Oil Pressure Alarm Action
Shutdown
Oil Press Alarm Delay
0:05
0:01 – 1:40
Sec
Temperature Check
Run
Off / Always / Run
High Temp Pre Alarm
220
150 - 300
Deg F
High Temp Alarm
230
150 - 300
Deg F
Temperature Alarm Action
Shutdown
Temp Alarm Delay
0:05
0:01 – 1:40
Min:Sec
Battery Volts Check
Off
Off / Always / Run
Low Battery Pre Alarm
12.0
0.0 – 40.0
Volts
Hi Battery Pre Alarm
15.0
0.0 – 40.0
Volts
Over Speed Check
Off
Off / Always / Run
Over Speed Alarm
3000
650 - 5000
RPM
Over Speed Alarm Delay
0:05
0:01 – 1:40
Min:Sec
1) Off / Always / Run – Describes when the parameter will be monitored for alarm conditions. Run
refers to when the engine is running. Off disables the alarm conditions. Always enables the alarm
constantly regardless of engine state.
2) Alarm Delay – The time period, after Sender Check Bypass, that the parameter must be on the
alarm condition before the alarm becomes latched.
