Convaid Cruiser 14 - Standard Footplate Assy Kit - Left

www.convaid.com14
Cruiser 14
Close-up
996010
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Footrest Assembly, LH
5049871
1
Footplate Adjustment Tube LH
5009692
1Footrest Extens. Housing Assy5006903
1Tube Connector 7/8" Heavy Duty100017
4
2Screw 1/4"-20 x 1-1/2" Flat Skt100262
5
1Detent Pin With Webbing Assembly5038796
1Thread Locker-Medium-Vibra-tite100690
7
6
4
57
2
1
Cruiser 10-12 Small Footplate Assembly Kit LH
Assembled
Exploded
996010
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Footrest Assembly, LH
5049871
1
Footplate Adjustment Tube LH
5009692
1Footrest Extens. Housing Assy5006903
1Tube Connector 7/8" Heavy Duty100017
4
2Screw 1/4"-20 x 1-1/2" Flat Skt100262
5
1Detent Pin With Webbing Assembly5038796
1Thread Locker-Medium-Vibra-tite100690
7
6
4
57
2
1
Cruiser 10-12 Small Footplate Assembly Kit LH
Assembled
Exploded
Assembled
FOOTPLATE
Standard Footplate Assy Kit - Left
Item Description Qty
1 Footrest Assembly: Standard, LH 1
2 Footplate Adjustment Tube, LH 1
3 Footrest Extension Housing Assembly 1
4 Tube Connector 7/8" Heavy Duty 1
5 Screw 1/4"-20 x 1-1/2" Flat Skt 2
6 Detent Pin With Webbing Assembly 1
7 Thread Locker-Medium-Vibra-tite 1
996110
#
Kit Includes
3
