CP12CW2 Portable Refrigerated Air Conditioner
10
11
Never try to dismantle the air conditioner yourself.
Problem Check
The air conditioner does not
run.
The air conditioner is not as
cool as it once was.
The air conditioner is too
noisy.
The compressor will not run.
In case of problems that cannot be fixed by using the above guide, or if service
on your air conditioner is required, please contact your dealer or designated
service agent.
TROUBLESHOOTING
As a policy of continual product improvement, this manual, its contents and specifications are subject to change without notice.
Model
Function
Cooling Capacity (Watts) †
Power Supply
Rated Input Power (Watts)
Fuse Type
Refrigerant Type / Charge (kg)
Water Ingress Protection Rating
Weight (kg)
Dimensions (mm)
(width / depth / height)
CP12CW2
Personal Cooling
3500
300
220-240V ~, 50Hz
1100
3.15A / 250V
R410A / 0.6
3.53
1.77
IPX0
450 / 393 / 746
High Side Pressure - Maximum (MPa)
Low Side Pressure - Maximum (MPa)
31.5
Is the air conditioner plugged in?
Is there a power failure?
Is the "WATER FULL" error code flashing?
Drain the tank as shown (Fig 12).
Is there direct sunshine? Remember to close
curtains or blinds.
Are windows or doors open?
More people in the room will generate more
heat.
Is there something in the room producing
excessive heat?
Is the exhaust fitted correctly or obstructed?
All exhaust air needs to be completely
removed from the room.
Is the filter dusty or dirty, restricting the
airflow?
Is the air inlet or outlet blocked?
Is the room temperature below the set
temperature?
Is the air conditioner positioned unevenly, so
as to create vibration?
Is the floor beneath the air conditioner
uneven?
Is the room temperature below the set
temperature?
5
P9
P10
A6958-410
