COOK EWD Series - Page 9

9PROPELLER WALL IO&M B51091-003
XLW / XMW
Exhaust
Suppl
y
Rotation
Air Flow
Rotation
2 3
4
12
12
4
5
Air Flow
6
7
7
1
10
13
13
2
3
5
6
1
10
11
11
9
9
8
8
XLWH / XMWH
Exhaust
Supply
Rotation
Rotation
2 3
Air Flow
Air Flow
6
1
4
5
11
11
8
12
10
9
2 3
6
1
4
5
7
8
12
10
9
13
13
7
Part Description Part Description
1 Power Assembly Rail 8 Motor
2 Base 9 Motor Plate
3 Prop 10 Drive Sheave
4 Power Assembly Feet (3) 11 Driven Sheave
5 Shaft 12 Belt
6 Bearings (2) 13 End Wire Guard
7 Venturi
Note: Since 2012, the venturi and base are one piece.
XLP / XLPH / XMP / XMPH
Supply
1
Exhaust
4
5
2
13
7
7
3
8
10
9
12
14
11
1
4
5
2
13
6
3
8
10
9
12
14
11
6
Air Flow
Air Flow
Part Description
1 Base
2 Prop
3 Venturi
4 Shaft
5 Bearings (2)
6 Motor
7 Motor Plate
8 Driven Sheave
9 Drive Sheave
10 Belt
11 Mounting Collar Angles (4)
12 Anchor Angles (2)
13 End Wire Guard
14 Shutters
Note: Since 2012, the venturi and base are one piece.
