Induction Hob by Cooke & Lewis
Getting started...
Installation
Installation instructions
Remove all the packing materials plus disposal statement.
Siting (See g.1)
Caution
Good ventilation is required around the appliance
for easier dissipation of heat and low power
consumption.
Sufcient clearance is required around the
appliance.
The appliance should not be placed near anything
that may echo.
> The induction hob must be well ventilated and the air inlet and outlet
must not be blocked.
Min. 750 mm
Min. 50 mm
Min. 20 mm
Air intake
520 mm
590 mm
55 mm
560 mm
490 mm
Air exit
Min. 5 mm
g. 1
