Figure 3 - Greasing rotisserie bearings
Lubricate rotisserie drive chain every six months, also check chain tension and adjust by
loosening bolts and using motor weight to create tension – Figure 4
Figure 4 - Rotisserie drive chain and tension adjustment
Clean the racks and inside of cooking chamber with a degreaser and power wash weekly.
(Recommended cleaner is Zep FS10184 Degreaser) NOTE: PROTECT ALL
ELECTRICAL COMPONENTS FROM MOISTURE DURING THIS PROCESS.
If the oven is stored outdoors care should be taken to insure that water does not get into
the pellet hopper. Wood pellets expand greatly when wet and will jam the auger system.
A vinyl cover for the hopper is highly recommended.
Brush the Convection fan blades off periodically – Figure 5.
Clean the pellet slide periodically to prevent pellet dust buildup – Figure 6.
Figure 5 – Convection Fan Cleaning Figure 6 – Pellet Slide Cleaning
