2.3 Capacity Variation Ratio According to Temperature
09K 12K
18K
Cooling
Cooling
Heating
Heating
32 33 34 35 36 37 38 39 43 –15 –10 –5 0 5 7 10
40 41 42
100
105
95
90
85
80
75
70
65
60
55
50
Outdoor temp. (˚C)
110
100
90
80
70
60
50
40
Outdoor temp. (˚C)
Capacity ratio (%)
Capacity ratio (%)
• Conditions
Indoor: DB27°C/WB19°C
Outdoor: DB35°C/WB24°C
Indoor air flow: High
Pipe length: 5m
• Conditions
Indoor: DB20°C/WB15°C
Outdoor: DB7°C/WB6°C
Indoor air flow: High
Pipe length: 5m
100
105
95
90
85
80
75
70
65
60
55
50
Outdoor temp. (˚C)
)%(oitaryticapaC
110
100
90
80
70
60
50
40
Outdoor temp. (˚C)
)%(oitaryticapaC
32
33 34 35 36 37 38 39 40 41 42 43
Cooling Heating
-15 -10 -5 0 5 7 10
• Conditions
Indoor: DB27°C/WB19°C
Outdoor: DB35°C/WB24°C
Indoor air flow: High
Pipe length: 5m
• Conditions
Indoor: DB20°C/WB15°C
Outdoor: DB7°C/WB6°C
Indoor air flow: High
Pipe length: 5m
