51
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
Product Code CV010W02000
1 Electric Box Assy 10000100274 1
2 Electric Box Sub-Assy 10000500127 1
3 Main Board 30138000676 1
4 Reactor 43130184 1
5 Terminal Board 42011113 1
6 Wire Clamp 71010003 1
7 Front Grill 22413027 1
8 Front Panel 0153304802 1
9 Axial Flow Fan 10333004 1
10 Chassis Sub-assy 01700000081P 1
11 Fan Motor 1501308506 1
12 Small Handle 26233100 1
13 Top Cover Sub-Assy 0125307002 1
14 Motor Support 0170310401 1
15 Condenser Assy 01100200333 1
16 Rear Grill 01473009 1
17 Electronic Expansion Valve 07135228 1
18 Cut off Valve 071302391 1
19 Big Handle 262334332 1
20 Valve 05103973 1
21 Valve Support 0171314201P 1
22 Right Side Plate Sub-Assy 0130317801 1
23 4-Way Valve Assy 03073240 1
24 Clapboard Sub-Assy 0123338502 1
25 Magnet Coil 4300040050 1
26 Compressor and Fittings 00103892 1
27 Drainage Connecter 06123401 1
28 Electrical Heater(Compressor) 7651300403 1
29 Electrical Heater(Chassis) 7651000414 1
CH-S09FVX
