55
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
Product Code CV010W01800
1 Front Grill 22413025 1
2 Front Panel 01535013P 1
3 Drainage Connecter 06123401 1
4 Chassis Sub-assy 02803270P 1
5 Drainage hole Cap 06813401 1
6 Compressor and ttings 00105246G 1
7 Magnet Coil 4300040045 1
8 4-Way Valve Assy 03015200069 1
9 Cut off Valve Assy 1/2 07133774 1
10 Cut off Valve Sub-Assy 07133058 1
11 Valve support assy 01715010P 1
12 Right Side Plate 0130509402P 1
13 Valve cover 22245002 1
14 Handle 26233053 1
15 Wiring Clamp 26115004 1
16 Electronic Expansion Valve assy 03017400018 1
17 Electric Expand Valve Fitting 4300876704 1
18 Rear Grill 01473043 1
19 Condenser Assy 0116348702 1
20 Reactor / 1
21 Clapboard Assy 01233153 1
22 Coping 01255005P 1
23 Supporting Board(Condenser) 01795010 1
24 Motor Support Sub-Assy 01705036 1
25 Fan Motor 1501506402 1
26 Axial Flow Fan 10335008 1
27 Left Side Plate 01305093P 1
28 left handle 26235254 1
29 Electric Box Assy 10000100266 1
30 Wire Clamp 71010003 1
31 Terminal Board 420111041 1
32 Electric Box 20113027 1
33 Radiator 49013060 1
34 Main Board 30138000672 1
35 Insulated Board (Cover of Electric Box) 20113003 1
36 Temperature Sensor 39000072 1
CH-S18FVX
