61
Installation and Maintenance
Service Manual
Procedure
Steps
Screws
Screws
Screws
Screws
拧下固定面罩的螺钉,拆下面罩。
面罩
4. 拆面罩
5. Remove axial ow blade
Remove the nut xing axial ow blade and
then remove the axial ow blade.
Nut
Axial ow blade
