4
Technical Information
Service Manual
Parameter Unit Value
Model
Product Code CV010001900
Power
Supply
Rated Voltage V
～
220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Indoor
Cooling Capacity(Min~Max) W 3500(600~3950)
Heating Capacity(Min~Max) W 3650(600~4700)
Cooling Power Input(Min~Max) W 980(220~1400)
Heating Power Input(Min~Max) W 1000(220~1580)
Cooling Current Input A 4.45
Heating Current Input A 4.55
Rated Input W 1580
Rated Current A 6.2
Air Flow Volume(SH/H/HM/M/LM/L/SL) m
3
/h 600/520/480/440/400/360/280
Dehumidifying Volume L/h 1.2
EER W/W 3.6
COP W/W 4.0
SEER W/W 6.3
HSPF W/W /
Application Area
m
3
108
Indoor
Unit
Indoor Unit Model
Indoor Unit Product Code CV010N01900
Fan Type Centrifugal
Fan Diameter Length(DXL) mm Φ80X370
Cooling Speed
(SH/H/HM/M/LM/L/SL)
r/min 750/650/600/550/500/450/350
Heating Speed
(SH/H/HM/M/LM/L/SL)
r/min 750/650/600/550/500/450/350
Fan Motor Power Output W 30
Fan Motor RLA A 0.15
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7
Evaporator Row-n Gap mm 2-1.3
Evaporator Coil Length (LXDXW) mm 511X25.4X400
Swing Motor Model MP24EB/MP24AE
Swing Motor Power Output W 1.5/1.5
Fuse Current A 3.15
Sound Pressure Level
(SH/H/HM/M/LM/L/SL)
dB (A) 38/35/32/30/28/26/24
Dimension (WXHXD) mm 700X600X215
Dimension of Carton Box (LXWXH) mm 785X682X280
Dimension of Package(LXWXH) mm 788X697X283
Net Weight kg 15
Gross Weight kg 18
CH-S12FVX
CH-S09FVX
