6
Technical Information
Service Manual
Parameter Unit Value
Model
Product Code CV010001800
Power
Supply
Rated Voltage V
～
220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Indoor
Cooling Capacity(Min~Max) W 5270(900~5600)
Heating Capacity(Min~Max) W 5500(900~6600)
Cooling Power Input(Min~Max) W 1420(350~2500)
Heating Power Input(Min~Max) W 1530(350~2500)
Cooling Current Input A 6.45
Heating Current Input A 6.95
Rated Input W 2500
Rated Current A 10.9
Air Flow Volume(SH/H/HM/M/LM/L/SL) m
3
/h 700/650/580/520/460/410/320
Dehumidifying Volume L/h 1.8
EER W/W 3.71
COP W/W 3.59
SEER W/W 5.8
HSPF W/W /
Application Area
m
3
159
Indoor
Unit
Indoor Unit Model
Indoor Unit Product Code CV010N01800
Fan Type Centrifugal
Fan Diameter Length(DXL) mm Φ80X370
Cooling Speed
(SH/H/HM/M/LM/L/SL)
r/min 840/800/720/650/580/530/410
Heating Speed
(SH/H/HM/M/LM/L/SL)
r/min 930/840/760/690/620/570/450
Fan Motor Power Output W 30
Fan Motor RLA A 0.15
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7
Evaporator Row-n Gap mm 2-1.3
Evaporator Coil Length (LXDXW) mm 511X25.4X400
Swing Motor Model MP24EB/MP24AE
Swing Motor Power Output W 1.5/1.5
Fuse Current A 3.15
Sound Pressure Level
(SH/H/HM/M/LM/L/SL)
dB (A) 40/38/36/34/32/30/28
Dimension (WXHXD) mm 700X215X600
Dimension of Carton Box (LXWXH) mm 785X280X682
Dimension of Package(LXWXH) mm 788X283X697
Net Weight kg 15
Gross Weight kg 18
CH-S18FVX
CH-S18FVX
