Cooper VR Series - Tank and Head Assembly Parts List

S260-20-9
19
Tank and Head Assembly Parts
(Figure 39)
Qty.
Item Catalog Per
No. Description Number Assy.
1 Bushing assembly, complete
(includes items 6, 7, 8 and 9)
Standard creepage KA160E7 6
17-inch creepage KA160E8 6
2 Capscrew, hex hd, 3/8-16 x
1-5/8, stl K730101137162Q 18
3 Bushing clamp KP41L 18
4 Clamping ring KP121L 6
5 Lower bushing gasket KP2020A29 6
6 Terminal KA143L900 1
7 Terminal gasket KP2090A57 1
8 Ceramic bushing
Standard creepage KP130VR 1
17-inch extra creepage KP318VR 1
9 Bushing rod KA160E907 1
10 Vented dipstick KA213VR 1
11 O-ring gasket KP2000A46 1
12 Capscrew, hex hd, 3/8-16
x 3, stl K73101137300Q 10
13 Washer KP2028A23 10
14 Combination nut and pin KP3061A3 10
15 Capscrew, hex hd,1/2-13
x 1-1/4, stl K730101150125Q 2
16 Split lockwasher, med,1/2, stl K900801050000Z 2
17 Lifting lug KP456H1 2
Qty.
Item Catalog Per
No. Description Number Assy.
18 Head casting (includes
operating shaft bushing) KA701VR 1
19 Oil seal KP259VR 1
20 Head gasket KP2103A6 1
21 Shaft and levers assembly KA23VR 1
22 Rubber seal KP2090A44 1
23 Indicator KA19VR 1
24 Roll pin, 3/16 x 1-1/8, stl K970801187112M 1
25 Washer KP164VR 1
26 External retaining ring KP2013A1 1
27 Shaft bearing KP88VR 1
28 Split lockwasher, med, 5/8, stl K900801062000Q 6
29 Capscrew, hex hd, 5/8-18 x 2,
stl K730101162200Q 6
30 Retaining ring, Type C, 1/4
stl (WA514) K970901250000M 6
31 Pin KP3124A18 3
32 Contact operating link KP17VR 3
33 Tank liner kit KA761H3-2 1
34 Tank assembly KA3VCR 1
35 Capscrew, hex hd, 1/2-13 x 1,
stl K730101150100Q 1
36 Parallel ground clamp KA227H 1
37 Pipe plug 1/2, sq hd KP2007A3 1
38 Oil sampling and drain valves KA809R 1
