Cooper VR Series - Type VLR Contact Assembly Parts List

S260-20-9
23
Type VLR Contact Assembly (Figure 42)
Qty.
Item Catalog Per
No. Description Number Assy.
9 Machine screw, rd hd, 10-32
x 2-1/2, stl K721501310250A 2
10 Split lockwasher, med
No. 10, stl K900801010000Z 2
11 Hex nut, 10-32, stl K881001332010A 2
12 Tube strap KP111 VLR 2
13 Contact tube band KA98VR 1
14 Movable contact yoke
assembly KA16VLR 1
15 Spacer KP1505R 1
16 Plain washer, 5/8 SAE,
steel K900201031000A 4
17 Stop nut KP2020A4 1
18 Roll pin, 1/8 x 13/16 K970801125081M 1
Qty
Item Catalog Per
No. Description Number Assy.
1 Hex jam nut, light, 5/8-18,
brass K880725318062A 4
2 Washer KP2028A4S 4
3 Split lockwasher, med, 5/8
bronze K900830062000A 2
4 Retaining ring, Type C 1/4
stl (WAS14) K970901250000M 2
5 Pin KP3124A18 1
6 Contact rod assembly KA5VLR 1
Stationary contact assembly
complete (includes items 7
through 13) KA4VLR1 1
7 Contact housing support KA3VLR 1
8 Stationary contact housing
assembly KA7VLR 1 2
