Cooper VR Series - Actuator Mechanism Parts List

S260-20-9
25
Actuator Mechanism Parts (Figure 43)
Qty.
Item Catalog Per
No. Descrliption Number Assy.
49 Plug assembly KA98NR 1
50 Terminal strip KP2101A7 1
51 Marker KP40VR 1
52 Machine screw, rd hd, 8-32
x 3/4, stl K721501108075Z 2
53 Split lockwasher, med, No. 8,
stl K900801008000Z 2
54 Hex nut, 8-32, stl K881001132008Z 2
55 Switch mounting panel KP344VR 1
56 Machine screw, rd hd, 100-32
x 3/4, stl K721501310075Z 3
57 Split lockwasher, med, No. 10,
stl K900801010000Z 3
58 Plain washer, No. 10, stl K900201010000Z 3
59 Spacer KP3007A37 3
60 Switch and latch assembly KA182VR900 2
61 Machine screw, rd hd, 8-32
x 1/2, stl K721501108050Z 4
62 Elastic stop nut, 8-32 KP2020A5 4
63 Spacer KP3007A35 2
64 Crank assembly KP141VR 1
65 Self-tap screw, pan hd,.10-32
x 1/8, sst KP751717110037A 1
66 Mounting clip KP1091ME 1
67 Latch-in spring KP72VR 1
68 Machine screw, rd hd, 10-32
x 7/8, stl K721501310087Z 2
69 Split lockwasher, med, No. 10
stl K900201010000Z 2
70 Hex nut, 10-32, stl K881001332010Z 2
71 Machine screw, rd hd, 5/16-18
x 1-1/4, brass K721525131125A 1
72 Flat washer, 5/16 AN, stl K900201032056Z 2
73 Hex nut, 5/16-28, stl K880201118031Q 1
74 Latch KP268VR 1
75 Wing nut K881201118031Z 1
76 Counter assembly KA28C03 1
77 Self-tap screw, rd hd, No. 6
x 3/8, sst K801515006037A 2
78 Capscrew, hex hd, 3/8-16
x 1-1/2, stl K730101137150Q 1
79 Hex nut, 3/8-16, stl K880201116037Q 1
80 Split lockwaser, med, 3/8, stl K900801037000Z 1
81 Plate, CLOSED KP729R 1
82 Nameplate KP131 VR 1
83 Control rating plate KP289VR1 6
84 Self-tap screw, rd hd, Type Z,
No. 2 x 3/16, stl K801515002018A 6
85 Cover KP158VR 1
86 Gasket KP649VR 1
87 Machine screw, rd hd, 10-32
x 3/4, sst K721515310075A 4
88 Split lockwasher, med, No. 10,
stl K900801010000Z 4
89 Hex nut, 10-32, stl K880201332010Z 4
90 Gasket KP78VR 1
91 Gasket KP77VR 1
92 Mechanism housing KA230VR1 1
93 Capscrew, hex hd, 3/8-16 x 1,
stl K730101137100Q 4
94 Split lockwasher, med, 3/8, stl K900801037000Z 4
Qty.
Item Catalog Per
No. Description Number Assy.
1 Cover KP129VR 1
2 Cover gasket KP2084A1 1
3 Plate, MANUAL TRIP KP245VR 1
4 Plate, OPEN KP730R 1
5 Self-tap screw, rd hd, Type Z,
No. 2 x 3/16, sst K801515002018A 4
6 Manual trip assembly KA65VR900 1
7 Spring KP157VR 1
8 Spacer KP3007A8 1
9 Plain washer, 1/4 AN, stl K900201026050Z 1
10 Plain washer, No. 10S, brass K900525020043A 1
11 Speed nut KP2005A1 1
12 Mounting plate KP87VR 1
13 Machine screw, rd hd, 10-32
x 3/4, sst K721515310075A 2
14 Split lockwasher, med, No. 10,
stl K900801010000Z 2
15 Trip solenoid assembly
120 vac KA185VR1 1
125 vdc KA185VR2 1
48 vdc KA185VR3 1
24 vdc KA185VR4 1
16 Machine screw, 10-32 x 1/2, stl K72150130050Z 4
17 Elastic stop nut, 10-32 KP2020A1 4
18 Nylon wire clip KP2006A1 1
19 Pin KP314VR 1
20 Link KP83VR 1
21 Spacer KP3004A24 1
22 Plain washer, No. 6 SAE, stl K900201006000Z 1
23 Retaining ring, Type C, 1/4,
stl (WA514) K970901250000M 1
24 Support and lever assembly KA41VR 1
25 Machine screw, 10-32 x 1/2, stl K721501310050Z 2
26 Elastic stop nut, 10-32 KP2020A1 2
27 Closing spring KP533GW 1
28 Retaining ring, Type C, 3/8,
stl (WA518) K970901375000M 1
29 Sleeve KP280VR 1
30 Retaining ring, Type C, 5/16,
stl (WA516) K970901312000M 1
31 Plain washer, No. 20S, brass K900525312000A 1
32 Spring link KP31VR 2
33 Spacer KP3011A6 1
34 Plain washer, 1/2, brass K900525056125A 1
35 Toggle assembly KA11 VR1 1
36 Retaining ring Type C, 5/16,
stl K970901312000A 2
37 Spacer KP3010A7 1
38 Pin KP3125A7 1
39 Opening spring KP35VR 2
40 Speed reducer (includes items
42 through 45) KA32VR 1
41 Capscrew, hex hd, 5/16-18
x 3/4, stl K731001131075Q 4
42 Split lockwasher, med, 5/16, stl K900801031000Z 4
43 Motor assembly KA225VR 1
44 Spacer KP3009A159 3
45 Split lockwasher, med, 14, stl K900801025000Z 3
46 Machine screw, rd hd, 1/4-28
x 1 -18, stl K721501325112Q 3
47 Receptacle assembly KA129VR 1
48 Self tap screw, rd hd, Type Z,
No. 6 x 3/8, stl K801515006037A 4
