Copower SANDOLAB TP - Page 18

18
Import:
It is used to import all the dyeing programs from USB device to HMI.
 Export Path: H:\HMI\HMI-000 (EX. H disk is the USB Device.)
 Export File Name: recipe.csv (It can be opened by Microsoft EXCEL.)
Main menu:
Program Import & Export:
Plug in a USB device to HMI,
click IMPORT&EXPORT
button with password
inputting
Click IMPORT button to
transfer all the dyeing
programs from USB
device to HMI.
Back to home page
