Safety
2
3
Residual heat indicators
A
fter using the hob, waste heat remains in the heating area. The
power nixie tube shows the code “H”, warning to be away from the
heating area.
Auto shut down protection
During the hob working, it is shut off automatically when the default
timing reach by the program if without operating. If several heating
zones work simultaneously, the hob will be automatically shut off when
anyone heating area reaches it’s default timer. The default working
timer for various power levels are shown in the table below:
Installation
S
election of installation equipment
Drill holes on the table surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 50 mm space shall
be preserved around the hole.
Be sure the thickness of the table surface is at least 30mm. Please select
heat-resistant table material to avoid larger deformation caused by the heat
radiation from the hotplate.
As shown in Figure (1)
1
Power level 1 2 3 4 5 6 7 8 9
D
efault working
time(hour)
8 8 8 4 4 4 2 2 2
8
Cooking Hob
Cooking Zones
3 Zones
Supply Voltage
220-240V~ 50Hz or 60Hz
Ins
talled Electric Power
5700W
Pr
oduct Size D×W×H(mm)
590X520X55
Building-in Dimensions A×B (mm)
560X 0
49
Technical Specification
CCVM300
