ProLine 124-221-321-324 Operator manual 85
UK
Table of contents
1. COMMISSIONING......................................................................................87
1.1 INTRODUCTION....................................................................................87
1.1.a. PURPOSE OF THE MANUAL ...........................................87
1.2 FOR YOUR SAFETY...............................................................................87
1.2.a. GENERAL WARNINGS AND INSTRUCTIONS.................88
1.2.b. LABELS PLACEMENT........................................................91
1.2.c
ELECTRICAL AND PNEUMATIC CONNECTIONS..............
97
1.2.d TECHNICAL DATA...............................................................99
1.2.e. AIR PRESSURE..................................................................100
1.3. ADDITIONAL RIM/TYRE INFORMATION.........................................101
1.4. INTENDED MACHINE USE...............................................................101
1.5. PERSONNEL TRAINING....................................................................101
1.6. PRELIMINARY CHECKS.....................................................................102
1.7. DURING USE......................................................................................102
1.8. OPTIONAL ACCESSORIES.................................................................102
2. TRANSPORT, STORAGE AND HANDLING...............................................103
3. UNWRAPPING..........................................................................................104
4. MOUNTING..............................................................................................105
5. LIFTING/HANDLING.................................................................................107
5.1 INSTALLATION AREA.........................................................................108
6. DESCRIPTION OF THE MACHINE...........................................................109
6.1. OPERATOR POSITION.......................................................................110
7. OVERALL DIMENSIONS (mm) ...............................................................110
8. MAIN WORKING ELEMENTS OF THE MACHINE...................................111
9. BASIC PROCEDURES - USE....................................................................115
9.1. PRELIMINARY CHECKS....................................................................116
9.2. DECIDING FROM WHICH SIDE OF THE WHEEL THE TYRE
MUST BE REMOVED................................................................................116
9.3. BEAD BREAKING...............................................................................117
9.4. CLAMPING THE WHEEL....................................................................119
9.5. WHEEL DEMOUNTING......................................................................123
9.5.a. TOOL HEAD POSITIONING (PROLINE 324-321)..........123
9.5.b. TOOL HEAD POSITIONING (PROLINE 124-221).........123
9.5.c. WHEEL DEMOUNTING...................................................124
9.6. WHEEL MOUNTING...........................................................................126
9.7 APPROVED UHP AND RUN FLAT TYRE DEMOUNTING AND
MOUNTING PROCEDURE........................................................................127
9.8. TYRE INFLATION................................................................................127
9.8.A. SAFETY INDICATIONS.....................................................127
9.8.B. TYRE INFLATION..............................................................129
